LiitoKala Lii-202 Lii-402 Lii-PD4 Lii-500 Lii-S8 Battery Charger 18650 26650 21700 AA AAA 3.7V Li-Ni-MH Battery

$10.79$39.95 (-50%)

Sold By: futuretechnologz
Clear
Compare
SKU: 1005003923412419 Category:
  • Brand Name: liitokala
  • Origin: CN(Origin)
  • Display screen: Yes
  • Quick charge: Yes
  • Type: Electric
  • Intelligent Charge: Yes
  • Certification: CE
  • Certification: FCC
  • Certification: RoHS
  • Model Number: LII-S8 LII-500 LII-PD4 LII-402 LII-202
  • Use: Standard Battery

Lii500
This product test data is for reference only. Do not make any evidence.


LiitoKala Lii – 500 specification
Thank you for using our products – Lii – 500, it is a high-end intelligent charger, with 4 channel independent rechargeable battery capacity testing/battery internal resistance detection/meter/short circuit protection, overcharge protection/temperature / 1.65 V to 1.65 V voltage can't charging function/USB 5 V output, and zero volt battery activation and so on ten big function, at the same time automatically timely monitoring battery charging, test process.
Lii – 500 can be filling a variety of different types of cylindrical lithium-ion battery and AA/AAA cylindrical nickel metal hydride batteries, widely used in strong light flashlight, electric tools, instruments and meters, electronic products such as digital camera battery. The use of safe, easy to carry, powerful, your home, tourism is a good helper.

LII-500

Lii-PD4 Dete1. Input : AC cable 110-240V 50/60Hz (included)/ DC 12V 1A(selective)

2. Output voltage: DC 4.2V for Li-Ion 3.7V

DC 4.35V for Li-Ion 3.8V( IMR)

DC 3.65V for LiFePO4

DC 1.48V for NiMH/NI-Cd

3. Output current: Li-Ion/IMR/LiFePO4 2000mA*1(only for slot#4),

1000mA*2, 500mA*3 500mA*4

NiMH/NiCd: 1000mA*2, 500mA*3 500mA*4

4. Constant voltage, cut-off current: less than 100mA

5. Standby current: less than 15mA

Compatible battery types and sizes

Li-ion / IMR/LiFePO4: 26650,21700,20700, 18650, 18490, 18350, 17670, 17500, 16340(RCR123), 14500, 10440

NiMH/Cd: AA, AAA,SC, C

Size and weight:

133mm x 100mm x 35mm (L x W x H)

Weight: approx175g (not including AC cable)

LII-PD4

LII-402  Smart universal charger

Features

– Micro USB DC 5V input;

– 4 charging current options (500mA / 700mA / 1000mA/ 2000mA)

2000mA designated 4th slot;

– LED display charging status is 25%, 50%, 75%, 100%;Overcharge,

short circuit protection;

– Automatic identification of battery type (lithium ion battery,

nickel metal hydride battery);

Specification

Input : DC 5V/2A

Output voltage : 1.48V/4.20V/3.65V/4.35V

Output current : 2000mA*1/1000mA*2700mA*3/500mA*4

Output USB : 5V/1000mA

Compatible with Ni-MH/Cd AA AAA A SC Sizes

3.7V Li-ion Battery include

26650,22650,26500,21700,18650,18490,17670,17500,17355,16340,14500,10440

LiitokalaUSB cable      1PCS

Liitokala packing bag  1PCS

Liitokala lii-202 Manual  1PCS

warming:

this charge is only for charging the cylindrical lithium-ion (3.7, 3.8), Ni-Mh / Ni-Cd, LiFePO4 (Li-Ion) batteries.
Please read these instructions before use; pay attention to the recommended charging current, never choose the wrong charging current
when the charge with 5V USB AC adapter, 2A-current AC adapter recommended
Charger ma hot during operation for a long time, handle with care!
please cut off the electricity and remove the battery from the charger when charging is complete.
indoor condition only !!
data mapping Charger for reference only; please refer to professional instrumentation, if you need accurate data
2. Features and Specifications:
Micro USB DC 5V input, two independent slots and charging channels with built-in micro-computer control system to ensure high efficiency
Two charging current parameters (0.5A / 1.0A)
Four LED indicators show the charging status (25%, 50%, 75%, 100%), and also shows the battery type, if inserted into the battery (1.2 V Ni-Mh, 3.2 in Li-Fe, 3.7 in Li-Ion, 3.85 in li-ion)
automatically identify Li-Ion and Ni-Mh; But, you need to adjust the charging mode for LiFePO4 and 3.85 in the lithium-ion battery
it can actively 0 V battery, but the device does not charge a 1.65 V ~ 1.85 V batteries types.
built with excessive charging protection, over-discharge protection and protection of polar reverse. besides, it can detect a broken battery.
Charing mode: instantaneous current and voltage.
PERMANENT charging current: Operating voltage in the 5V-2A (Micro-connector)
Standard automatic 5 V / 1000 mAh USB output port
3. Select the button, LED and function.
MODE button:
click to select the type of battery when inserting the battery. it will begin to charge the battery after fixing the battery type (please noted that it will automatically identify Li-Ion and Ni-Mh, no need to choose manually)
press and hold for 2 seconds, when after connecting to power, it can be switched between charging current of 0.5A and 1.0A;
Led indicator
connect the charger to power, all LED indicators will be on when the battery is inserted after 5 seconds, the LED will be turned off except for the indicator 0.5A current
when the battery is inserted into the device, 4 LEDs will be turned on and 3.7 V LED indictors blink, then please press the MODE button to set the correct type of battery. it will begin to charge the battery after 5 seconds, and the LED indictors show the charging status.
Press the MODE button to show the type of battery (5 seconds) during charging and return to show the charging status
it can show the remaining battery power, if you put the battery in the charger (with no connection to the power charging)
USB output indicator: When the USB output is detected, the volume of the battery indicators will be on for 10 seconds and then off, press the button to show the battery volume speed.
4. Specification:
Input: Micro USB DC 5V / 2A
Output: 1.4, 4.2V ± 05, 3.65 ± 05, 4.35 ± 05
Output Current: 500/1000 mAh
constant voltage charging cut-off current: <100 mAh
Standby Current: <15 mAh
5. USB output function
USB output load voltage: 4.90 V-5.30
Output Current: 1000 mAh (1A)
Idle Current: <1 mAh
the output voltage of 4.75 V-5.25 V, when the current 1000 mAh
output over-voltage protection: 3.0 ± 1
6. Compatibility
li-ion / IMR: 18650, 18490, 18350, 17670, 17500, 16340 (RCR123), 14500, 10440
7. Size
112 mm × 60 mm × 30 mm / 86 g + 15 g USB cable
